Features |
|
|
- |
Display 4000 counts |
|
- |
Jaw Opening Ø30mm/1.2" |
|
- |
Auto Ranging |
|
- |
Auto Power Off |
|
- |
True RMS For AC Voltage |
|
- |
Low Pass Filter Function (50/60Hz) |
|
- |
Zero adjustment |
|
- |
MAX/MIN |
|
- |
Diode Open Voltage 3.2V |
|
- |
Continuity Buzzer <40Ω |
|
- |
Data Hold |
|
- |
Low Battery Display |
|
Features |
|
|
- |
Display 4000 counts |
|
- |
Jaw Opening Ø30mm/1.2" |
|
- |
Auto Ranging |
|
- |
Auto Power Off |
|
- |
True RMS For AC Voltage |
|
- |
Low Pass Filter Function (50/60Hz) |
|
- |
Zero adjustment |
|
- |
MAX/MIN |
|
- |
Diode Open Voltage 3.2V |
|
- |
Continuity Buzzer <40Ω |
|
- |
Data Hold |
|
- |
Low Battery Display |
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
4V/40V/400V/600V |
1mV/10mV/100mV/1V |
±(0.5%+4) |
|
AC Voltage |
4V/40V/400V/600V |
1mV/10mV/100mV/1V |
±(1.0%+3) |
|
AC Current |
4mA/40mA (50/60Hz) |
1μA/10μA |
±(2.0%+10) |
|
400mA/4A/40A (50/60Hz) |
0.1mA/1mA/10mA |
±(2.0%+5) |
|
|
150A (50/60Hz) |
0.1A |
±(2.0%+10) |
|
|
4mA/40mA (40~1kHz) |
1μA/10μA |
±(3.0%+5) |
|
|
400mA/4A/40A (40~1kHz) |
0.1mA/1mA/10mA |
±(3.0%+3) |
|
|
150A (40~1kHz) |
0.1A |
±(3.0%+5) |
|
|
Resistance |
400Ω/4KΩ/40KΩ/400KΩ/4MΩ |
0.1Ω/1Ω/10Ω/100Ω/1KΩ |
±(0.8%+3) |
|
40MΩ |
10kΩ |
±(1.0%+3) |
|
|
Capacitance |
40nF/400nF/4uF |
0.01nF/0.1nF/1nF |
±(3.0%+8) |
|
40uF/400uF/4mF/40mF |
10nF/100nF/1uF/10uF |
±(3.0%+8) |
|
|
Temperature |
-20°C～0°C/-4°F～32°F |
0.1°C /0.1°F |
±(3.0%+5) |
|
0°C～400°C/32°F～752°F |
0.1°C /0.1°F |
±(1.5%+5) |
|
|
400°C～1000°C/ 752°F～1832°F |
1°C /1°F |
±(3.0%+5) |
