Features |
|
|
- |
Display 6000 Counts |
|
- |
Jaw Opening Ø26mm/1.0" |
|
- |
Auto range |
|
- |
Auto Power Off |
|
- |
Dual Display |
|
- |
Continuity Buzzer <40Ω |
|
- |
Data Auto hold |
|
- |
MAX/MIN |
|
- |
Display Backlight |
|
- |
Low Battery Display |
|
Features |
|
|
- |
Display 6000 Counts |
|
- |
Jaw Opening Ø26mm/1.0" |
|
- |
Auto range |
|
- |
Auto Power Off |
|
- |
Dual Display |
|
- |
Continuity Buzzer <40Ω |
|
- |
Data Auto hold |
|
- |
MAX/MIN |
|
- |
Display Backlight |
|
- |
Low Battery Display |
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
6V/60V/600V |
0.01V/0.1V/1V |
±(0.5%+3) |
|
AC Voltage |
6V/60V/600V |
0.01V/0.1V/1V |
±(0.8%+5) |
|
AC Current |
2A/20A/200A |
0.01A/0.01A/0.1A |
±(2.5%+8) |
|
600A |
1A |
±(3.0%+10) |
|
|
Resistance |
2kΩ/20kΩ/200kΩ/2MΩ |
0.001kΩ/0.01kΩ/0.1kΩ/0.001MΩ |
±(0.8%+3) |
|
10MΩ |
0.01MΩ |
±(1.0%+5) |
|
|
Frequency (Clamp) |
60Hz/600/3kHz |
0.1Hz/1Hz/10Hz |
±(1.0%+5) |
|
Frequency (Plug) |
60Hz/600/3kHz |
0.1Hz/1Hz/10Hz |
±(1.0%+5) |
|
Duty Cycle |
10%～90% |
1% |
±2.0% |
